We're professional screw press juicer manufacturers and suppliers in China, to buy or wholesale screw juicer from our factory. For quotation or if you have any questions, contact us now for customized screw juice extractor and price.
Machine Model: LZ-0.5
The equipment adopts spiral propelling and extruding,uses gradual contraction of spiral chamber to realize squeezing of materials. The machine is suitable for juicing fruits and vegetables that have been crushed.
This machine can press juice from fruits such as tomato, pine- apple, apple orange etc.
Model | LZ-0.5 | LZ-1.5 | LZ-2.5 |
Production capacity | 0.5t/h | 1.5t/h | 2.5t/h |
Power | 1.5kw | 4kw | 11kw |
Overall dimension | 1000x320x1280mm | 1560x450x1340mm | 2200x600x1960mm |
This machine is composed of front support, feeding entrance, spiral, filter, juice container back support, dregs outlet. The spiral is supported by rolling beating at one end, and by hard wheel beating at the other end.
The spiral is driven by drive motor through a pair of pulley.
Gradually, the minor diameter increase and meanwhile the pitch decrease. So when the fruit are fed in and driven by the spiral, the red cement of the space between the axle and the inside wall results to the press on the fruits.
Looking from feeding entrance to dregs outlet, the axle rotates clockwise.
The juice flew into the juice container at the bottom while the dregs are let out through the annular space between the spiral and pressure-adjusting cone, when the gar decrease and the dregs rate will reduce. But when the volume of the gar is too small, granular of dregs will be extrude through the filter with juice. So the magnitude of the gar depends on the demand of client’s cleaned on technology.
The machine should be installed levelly and fixed by mounting bolt.
The gar should be adjusted the biggest when workers start the machine. Reduce it to meet the demand of technology and fix the position of hand wheel by make.
Raw material should be fed evenly. No feeding of rigid thing into feeding entrance of else the palter will be drainage.
